Okay, so youve got a pier installation quote in your hand. Congratulations, youre one step closer to getting that settled foundation! I've named the crack in my basement wall "Harold" because we've been together so long it deserved a proper title house leveling service Des Plaines Facebook. But lets be honest, these quotes can look like a foreign language. Its a jumble of terms, numbers, and cryptic abbreviations. Dont panic! Were going to decode it together, starting with that initial consultation and site assessment line.


Think of the initial consultation as the "getting to know you" phase. A reputable company isnt going to slap in piers willy-nilly. They need to understand why your house is settling, whats causing the problem, and what the soil is like beneath your foundation. This is where the site assessment comes in.


The site assessment is like a doctors examination for your foundation. The inspector should be looking for cracks, sticking doors or windows, sloping floors – all the telltale signs of foundation movement. Theyll likely ask you questions about the history of the house, any previous repairs, and any drainage issues youve noticed.


This assessment isnt just a visual inspection, though. Often, it includes soil testing. This involves taking samples of the soil around your foundation to determine its composition and load-bearing capacity. This is crucial because different types of soil react differently to moisture, and that influences how the piers need to be installed and how many are required.


Now, why is this "decoding" relevant to the quote? Because its usually the first line item! You might see it listed as "Initial Consultation," "Site Evaluation," or something similar. This line covers the cost of the inspectors time, expertise, and potentially the soil testing.


Pay close attention to what this line includes. Is it a flat fee? Does it cover multiple visits if needed? Does it include a detailed report of their findings? A comprehensive assessment is worth its weight in gold. It ensures the pier installation is tailored to your specific problem, preventing future issues and saving you money in the long run.


If the quote jumps straight to pier installation costs without mentioning any kind of assessment, thats a major red flag. It suggests the company isnt taking the time to properly diagnose the problem, and theyre likely offering a cookie-cutter solution that may not be effective.


In short, that initial consultation and site assessment line is the foundation of a successful pier installation. Its the crucial step that ensures the whole project is built on solid ground (literally!). So, ask questions, understand whats included, and dont be afraid to shop around for a company that prioritizes a thorough and informative assessment. Your foundation will thank you for it.

Okay, lets talk about piers. Specifically, how understanding the pier type and its placement is crucial when youre wading through those installation quotes. I mean, a quote that just says "Install piers" is about as helpful as a chocolate teapot, right? You need details!


Think of it like this: piers are the foundations support system, the unsung heroes holding everything up. But there are different kinds of heroes, and each has its strengths and weaknesses. Were talking about things like concrete piers, helical piers, steel piers, and even variations within those categories. The type of pier chosen will impact the cost, the installation method, and ultimately, the stability of your foundation. A helical pier, for example, might be great for reaching deep into stable soil, but it could be overkill (and pricier!) if youre dealing with a less challenging soil profile.


Then theres the placement. This isnt just about sticking them in the ground randomly. A good quote will specify the number of piers, their spacing, and their location relative to the existing foundation. Why? Because the placement needs to address the specific problem areas. Are you seeing sagging floors? Cracks in the walls? The pier placement should directly correlate to those issues. A quote that doesnt explain why the piers are going where they are is a red flag. It suggests a lack of understanding of the underlying problem or, worse, a cookie-cutter approach that might not actually solve anything.


So, when youre looking at that quote, dig into the details. Ask questions! What kind of piers are they using? Why that type? Where are they placing them? Why that specific location? A good contractor will be able to explain their reasoning clearly and confidently. Understanding the pier type and placement is the key to knowing if youre getting a solution tailored to your needs, or just a generic band-aid on a structural problem. And that understanding is what separates a good quote from a potentially expensive mistake.

Material Procurement and Quality Control Procedures

Alright, let's talk about the nitty-gritty of pier installation quotes, specifically focusing on the "Material Costs: Pier Components and Quantities" line. When you see this on your quote, dont glaze over! This is where you get a real sense of what you're actually paying for. Its essentially the recipe for your pier system, outlining each ingredient and how much of it theyre planning to use.


Think of it like this: you wouldnt just agree to a restaurant bill without knowing what dishes you ordered, right? Same principle applies here. This section should break down the individual components of the pier system – things like the steel piers themselves, the brackets that connect the piers to your foundation, the shims used for leveling, and any other specialized hardware.


The "quantities" part is equally important. Are they using enough piers to properly support the load? Are they using appropriately sized brackets? This is where doing a little homework beforehand helps. Research what a typical pier installation looks like for your soil type and house size. That way, you can compare the quantities listed on the quote with what seems reasonable.


Dont be afraid to ask questions! If you see something that doesnt make sense, or if the quantities seem low compared to other quotes youve received, bring it up. A reputable contractor will be happy to explain their reasoning and walk you through the calculations they used to determine the necessary materials. Ultimately, understanding this section of the quote empowers you to make an informed decision and ensures you're getting a fair price for a robust and reliable pier system. Its about more than just the bottom line; its about peace of mind knowing your foundation is in good hands (and supported by the right amount of steel!).

Material Procurement and Quality Control Procedures

Inspection and Testing Protocols During Foundation Repair

Okay, so youre staring at a pier installation quote, and one of the lines that probably jumps out at you is "Labor Expenses." Its often a big chunk of the total cost, and for good reason. Two major factors drive that labor expense: installation time and crew size. Think of it like this: the faster they can get the job done with fewer people, the less youll pay. But its not always that simple.


Installation time is pretty straightforward. A small, simple pier might only take a day or two to put in. A larger, more complex pier, especially one in difficult conditions like deep water or rocky terrain, could take a week or even longer. That time translates directly to labor hours, and labor hours cost money. The quote should ideally give you a reasonable estimate, and a good installer will be able to explain the factors that contribute to that estimate.


Then theres the crew size. A smaller crew might seem cheaper, but consider this: a larger, more experienced crew might actually finish the job faster, ultimately saving you money. Plus, a larger crew can handle heavier materials and more complex tasks more safely and efficiently. A too-small crew might struggle, leading to delays, mistakes, and even potential injuries. So, while a smaller crew might seem appealing on paper, its important to understand why the installer chose that particular crew size and whether its appropriate for the scope of your project. A reputable installer will be transparent about their reasoning and be able to justify the crew size theyve allocated to your pier project. Dont be afraid to ask questions! Understanding how installation time and crew size impact the labor expenses will help you make a more informed decision.

Documentation and Reporting for Permitting Compliance and QA/QC

Equipment and Permitting Fees: Unveiling Hidden Costs


So, youre getting a pier installed. Exciting! Youve probably envisioned lazy afternoons fishing, breathtaking sunsets, and maybe even a little private sunbathing. But before you get lost in the idyllic imagery, lets talk about the less glamorous, but utterly crucial, part of the process: the quote. Specifically, the line that often reads "Equipment and Permitting Fees." This seemingly simple phrase can be a real Pandoras Box of expenses if you dont understand what it entails.


Think of it this way: building a pier isnt like assembling IKEA furniture. Its a construction project, often over water. This requires specialized equipment. Were talking barges, pile drivers, maybe even underwater welding gear. The cost of renting or operating this equipment can be significant, and that cost is inevitably passed on to you. Dont be afraid to ask for a breakdown. What specific equipment is needed, and what portion of the fee covers its use? A reputable contractor will be transparent about these charges.


Then theres the dreaded "P" word: Permitting. Building on or near waterways is heavily regulated, and rightly so. Environmental concerns, navigational safety, and property rights all come into play. Securing the necessary permits from local, state, and even federal agencies can be a complex and time-consuming process. The fees associated with these permits can vary wildly depending on the scope of the project and the location. A contractor who is experienced in pier construction will not only know which permits are required but should also be able to provide a realistic estimate of the associated costs.


The key takeaway here is to not let "Equipment and Permitting Fees" be a vague, catch-all phrase. Ask questions. Demand clarification. Understand exactly what youre paying for. A detailed quote gives you the power to compare bids accurately and avoids unpleasant surprises down the line. After all, you want to enjoy your new pier, not be burdened by unexpected expenses. A little due diligence upfront can save you a lot of headaches, and money, in the long run.

Risk Management and Mitigation Strategies in Project Logistics

Warranty and Guarantee Details: Protecting Your Investment


When youre staring at a pier installation quote, it can feel like deciphering a foreign language. Amidst the numbers and technical jargon, its easy to overlook a critical section: the warranty and guarantee details. But trust me, skipping over this part is like buying a car without knowing if the engines covered. Its this section that safeguards your significant investment.


Think of the warranty as the pier installers promise. It outlines what theyll cover if something goes wrong after the installation. What kind of issues are covered? Is it just material defects, or does it include labor costs for repairs? How long does the coverage last – is it a year, five years, or even longer? These are crucial questions to ask. A longer warranty period is generally a good sign, indicating the installers confidence in their work.


The guarantee, on the other hand, often refers to the installers assurance of the quality of their workmanship. Does the guarantee cover settling issues or other performance-related problems? Its important to understand the difference between a warranty and a guarantee, and to know what specific issues each covers.


Dont hesitate to grill the installer with questions. What are the exclusions to the warranty or guarantee? Are there specific maintenance requirements you need to follow to keep the warranty valid? A reputable installer will be transparent and happy to answer your questions. They should be able to articulate the details in plain language, not just industry-specific terms you cant understand.


Ultimately, understanding the warranty and guarantee details gives you peace of mind. Its your safety net, protecting you from unexpected expenses and headaches down the road. It demonstrates the installers commitment to quality and their belief in the longevity of their work. So, before you sign on the dotted line, take the time to carefully review this section. Its an investment in your investment, ensuring your pier provides enjoyment for years to come.

Post-Repair Verification and Long-Term Monitoring for QA/QC

Okay, so youve finally got those pier installation quotes in front of you, and youre wading through the details. Its a lot, right? But before you just pick the cheapest one, lets talk about something super important: how youre actually going to pay for this thing. Understanding the payment schedule and available financing options can make a huge difference in how this whole project impacts your wallet, both now and down the road.


First, the payment schedule. This is basically the contractors roadmap for getting paid. A reputable contractor will rarely, if ever, ask for the entire amount upfront. Instead, theyll break it down into installments, often tied to milestones. For example, you might see an initial deposit to secure the project and cover initial material costs. Then, you might have further payments once the crew is on site, after the piers are installed, and finally, a last payment after the inspection and any cleanup. This protects both you and the contractor. Youre not out all the money if something goes sideways, and the contractor is assured theyll get paid for the work they complete. Pay close attention to these milestones and make sure they are clearly defined in the contract. Dont be afraid to ask questions if anything is unclear.


Now, lets talk financing. Pier installation can be a significant investment, and not everyone has that kind of cash lying around. If thats you, dont panic! Many contractors offer financing options, either directly through them or through partnerships with lending institutions. These options can range from personal loans to home equity lines of credit (HELOCs). Some contractors may even offer installment plans themselves. The key here is to shop around and compare interest rates, terms, and fees. A low initial interest rate might sound appealing, but make sure you understand the long-term implications and whether that rate is fixed or variable. A HELOC can be a good option if you have equity in your home, but remember that youre putting your home on the line. Carefully consider your budget and ability to repay the loan before committing to any financing option. Ultimately, understanding the payment schedule and exploring all available financing options will help you make an informed decision that fits your financial situation and ensures a smooth pier installation process.

Drilling of deep piles of diameter 150 cm in bridge 423 near Ness Ziona, Israel



A deep foundation installation for a bridge in Napa, California, United States.
Pile driving operations in the Port of Tampa, Florida.

A pile or piling is a vertical structural element of a deep foundation, driven or drilled deep into the ground at the building site. A deep foundation is a type of foundation that transfers building loads to the earth farther down from the surface than a shallow foundation does to a subsurface layer or a range of depths.

Deep foundations of The Marina Torch, a skyscraper in Dubai

There are many reasons that a geotechnical engineer would recommend a deep foundation over a shallow foundation, such as for a skyscraper. Some of the common reasons are very large design loads, a poor soil at shallow depth, or site constraints like property lines. There are different terms used to describe different types of deep foundations including the pile (which is analogous to a pole), the pier (which is analogous to a column), drilled shafts, and caissons. Piles are generally driven into the ground in situ; other deep foundations are typically put in place using excavation and drilling. The naming conventions may vary between engineering disciplines and firms. Deep foundations can be made out of timber, steel, reinforced concrete or prestressed concrete.

Driven foundations

[edit]
Pipe piles being driven into the ground
Illustration of a hand-operated pile driver in Germany after 1480

Prefabricated piles are driven into the ground using a pile driver. Driven piles are constructed of wood, reinforced concrete, or steel. Wooden piles are made from the trunks of tall trees. Concrete piles are available in square, octagonal, and round cross-sections (like Franki piles). They are reinforced with rebar and are often prestressed. Steel piles are either pipe piles or some sort of beam section (like an H-pile). Historically, wood piles used splices to join multiple segments end-to-end when the driven depth required was too long for a single pile; today, splicing is common with steel piles, though concrete piles can be spliced with mechanical and other means. Driving piles, as opposed to drilling shafts, is advantageous because the soil displaced by driving the piles compresses the surrounding soil, causing greater friction against the sides of the piles, thus increasing their load-bearing capacity. Driven piles are also considered to be "tested" for weight-bearing ability because of their method of installation.[citation needed]

Pile foundation systems

[edit]

Foundations relying on driven piles often have groups of piles connected by a pile cap (a large concrete block into which the heads of the piles are embedded) to distribute loads that are greater than one pile can bear. Pile caps and isolated piles are typically connected with grade beams to tie the foundation elements together; lighter structural elements bear on the grade beams, while heavier elements bear directly on the pile cap.[citation needed]

Monopile foundation

[edit]

A monopile foundation utilizes a single, generally large-diameter, foundation structural element to support all the loads (weight, wind, etc.) of a large above-surface structure.

A large number of monopile foundations[1] have been utilized in recent years for economically constructing fixed-bottom offshore wind farms in shallow-water subsea locations.[2] For example, the Horns Rev wind farm in the North Sea west of Denmark utilizes 80 large monopiles of 4 metres diameter sunk 25 meters deep into the seabed,[3] while the Lynn and Inner Dowsing Wind Farm off the coast of England went online in 2008 with over 100 turbines, each mounted on a 4.7-metre-diameter monopile foundation in ocean depths up to 18 metres.[4]

The typical construction process for a wind turbine subsea monopile foundation in sand includes driving a large hollow steel pile, of some 4 m in diameter with approximately 50mm thick walls, some 25 m deep into the seabed, through a 0.5 m layer of larger stone and gravel to minimize erosion around the pile. A transition piece (complete with pre-installed features such as boat-landing arrangement, cathodic protection, cable ducts for sub-marine cables, turbine tower flange, etc.) is attached to the driven pile, and the sand and water are removed from the centre of the pile and replaced with concrete. An additional layer of even larger stone, up to 0.5 m diameter, is applied to the surface of the seabed for longer-term erosion protection.[2]

Drilled piles

[edit]
A pile machine in Amsterdam.

Also called caissons, drilled shafts, drilled piers, cast-in-drilled-hole piles (CIDH piles) or cast-in-situ piles, a borehole is drilled into the ground, then concrete (and often some sort of reinforcing) is placed into the borehole to form the pile. Rotary boring techniques allow larger diameter piles than any other piling method and permit pile construction through particularly dense or hard strata. Construction methods depend on the geology of the site; in particular, whether boring is to be undertaken in 'dry' ground conditions or through water-saturated strata. Casing is often used when the sides of the borehole are likely to slough off before concrete is poured.

For end-bearing piles, drilling continues until the borehole has extended a sufficient depth (socketing) into a sufficiently strong layer. Depending on site geology, this can be a rock layer, or hardpan, or other dense, strong layers. Both the diameter of the pile and the depth of the pile are highly specific to the ground conditions, loading conditions, and nature of the project. Pile depths may vary substantially across a project if the bearing layer is not level. Drilled piles can be tested using a variety of methods to verify the pile integrity during installation.

Under-reamed piles

[edit]

Under-reamed piles have mechanically formed enlarged bases that are as much as 6 m in diameter.[citation needed] The form is that of an inverted cone and can only be formed in stable soils or rocks. The larger base diameter allows greater bearing capacity than a straight-shaft pile.

These piles are suited for expansive soils which are often subjected to seasonal moisture variations, or for loose or soft strata. They are used in normal ground condition also where economics are favorable. [5][full citation needed]

Under reamed piles foundation is used for the following soils:-

1. Under reamed piles are used in black cotton soil: This type of soil expands when it comes in contact with water and contraction occurs when water is removed. So that cracks appear in the construction done on such clay. An under reamed pile is used in the base to remove this defect.

2. Under reamed piles are used in low bearing capacity Outdated soil (filled soil)

3.Under reamed piles are used in sandy soil when water table is high.

4. Under reamed piles are used, Where lifting forces appear at the base of foundation.

Augercast pile

[edit]

An augercast pile, often known as a continuous flight augering (CFA) pile, is formed by drilling into the ground with a hollow stemmed continuous flight auger to the required depth or degree of resistance. No casing is required. A cement grout mix is then pumped down the stem of the auger. While the cement grout is pumped, the auger is slowly withdrawn, conveying the soil upward along the flights. A shaft of fluid cement grout is formed to ground level. Reinforcement can be installed. Recent innovations in addition to stringent quality control allows reinforcing cages to be placed up to the full length of a pile when required.[citation needed]

Augercast piles cause minimal disturbance and are often used for noise-sensitive and environmentally-sensitive sites. Augercast piles are not generally suited for use in contaminated soils, because of expensive waste disposal costs. In cases such as these, a displacement pile (like Olivier piles) may provide the cost efficiency of an augercast pile and minimal environmental impact. In ground containing obstructions or cobbles and boulders, augercast piles are less suitable as refusal above the design pile tip elevation may be encountered.[citation needed]

Small Sectional Flight Auger piling rigs can also be used for piled raft foundations. These produce the same type of pile as a Continuous Flight Auger rig but using smaller, more lightweight equipment. This piling method is fast, cost-effective and suitable for the majority of ground types.[5][6]

Pier and grade beam foundation

[edit]

In drilled pier foundations, the piers can be connected with grade beams on which the structure sits, sometimes with heavy column loads bearing directly on the piers. In some residential construction, the piers are extended above the ground level, and wood beams bearing on the piers are used to support the structure. This type of foundation results in a crawl space underneath the building in which wiring and duct work can be laid during construction or re-modelling.[7]

Speciality piles

[edit]

Jet-piles

[edit]

In jet piling high pressure water is used to set piles.[8] High pressure water cuts through soil with a high-pressure jet flow and allows the pile to be fitted.[9] One advantage of Jet Piling: the water jet lubricates the pile and softens the ground.[10] The method is in use in Norway.[11]

Micropiles

[edit]

Micropiles are small diameter, generally less than 300mm diameter, elements that are drilled and grouted in place.  They typically get their capacity from skin friction along the sides of the element, but can be end bearing in hard rock as well. Micropiles are usually heavily reinforced with steel comprising more than 40% of their cross section. They can be used as direct structural support or as ground reinforcement elements.  Due to their relatively high cost and the type of equipment used to install these elements, they are often used where access restrictions and or very difficult ground conditions (cobbles and boulders, construction debris, karst, environmental sensitivity) exists or to retrofit existing structures.  Occasionally, in difficult ground, they are used for new construction foundation elements. Typical applications include underpinning, bridge, transmission tower and slope stabilization projects.[6][12][13][14]

Tripod piles

[edit]

The use of a tripod rig to install piles is one of the more traditional ways of forming piles. Although unit costs are generally higher than with most other forms of piling,[citation needed] it has several advantages which have ensured its continued use through to the present day. The tripod system is easy and inexpensive to bring to site, making it ideal for jobs with a small number of piles.[clarification needed]

Sheet piles

[edit]
Sheet piles are used to restrain soft soil above the bedrock in this excavation

Sheet piling is a form of driven piling using thin interlocking sheets of steel to obtain a continuous barrier in the ground. The main application of sheet piles is in retaining walls and cofferdams erected to enable permanent works to proceed. Normally, vibrating hammer, t-crane and crawle drilling are used to establish sheet piles.[citation needed]

Soldier piles

[edit]
A soldier pile wall using reclaimed railway sleepers as lagging.

Soldier piles, also known as king piles or Berlin walls, are constructed of steel H sections spaced about 2 to 3 m apart and are driven or drilled prior to excavation. As the excavation proceeds, horizontal timber sheeting (lagging) is inserted behind the H pile flanges.

The horizontal earth pressures are concentrated on the soldier piles because of their relative rigidity compared to the lagging. Soil movement and subsidence is minimized by installing the lagging immediately after excavation to avoid soil loss.[citation needed] Lagging can be constructed by timber, precast concrete, shotcrete and steel plates depending on spacing of the soldier piles and the type of soils.

Soldier piles are most suitable in conditions where well constructed walls will not result in subsidence such as over-consolidated clays, soils above the water table if they have some cohesion, and free draining soils which can be effectively dewatered, like sands.[citation needed]

Unsuitable soils include soft clays and weak running soils that allow large movements such as loose sands. It is also not possible to extend the wall beyond the bottom of the excavation, and dewatering is often required.[citation needed]

Screw piles

[edit]

Screw piles, also called helical piers and screw foundations, have been used as foundations since the mid 19th century in screw-pile lighthouses.[citation needed] Screw piles are galvanized iron pipe with helical fins that are turned into the ground by machines to the required depth. The screw distributes the load to the soil and is sized accordingly.

Suction piles

[edit]

Suction piles are used underwater to secure floating platforms. Tubular piles are driven into the seabed (or more commonly dropped a few metres into a soft seabed) and then a pump sucks water out at the top of the tubular, pulling the pile further down.

The proportions of the pile (diameter to height) are dependent upon the soil type. Sand is difficult to penetrate but provides good holding capacity, so the height may be as short as half the diameter. Clays and muds are easy to penetrate but provide poor holding capacity, so the height may be as much as eight times the diameter. The open nature of gravel means that water would flow through the ground during installation, causing 'piping' flow (where water boils up through weaker paths through the soil). Therefore, suction piles cannot be used in gravel seabeds.[citation needed]

Adfreeze piles

[edit]
Adfreeze piles supporting a building in Utqiaġvik, Alaska

In high latitudes where the ground is continuously frozen, adfreeze piles are used as the primary structural foundation method.

Adfreeze piles derive their strength from the bond of the frozen ground around them to the surface of the pile.[citation needed]

Adfreeze pile foundations are particularly sensitive in conditions which cause the permafrost to melt. If a building is constructed improperly then it can melt the ground below, resulting in a failure of the foundation system.[citation needed]

Vibrated stone columns

[edit]

Vibrated stone columns are a ground improvement technique where columns of coarse aggregate are placed in soils with poor drainage or bearing capacity to improve the soils.[citation needed]

Hospital piles

[edit]

Specific to marine structures, hospital piles (also known as gallow piles) are built to provide temporary support to marine structure components during refurbishment works. For example, when removing a river pontoon, the brow will be attached to hospital pile to support it. They are normal piles, usually with a chain or hook attachment.[citation needed]

Piled walls

[edit]
Sheet piling, by a bridge, was used to block a canal in New Orleans after Hurricane Katrina damaged it.

Piled walls can be drivene or bored. They provide special advantages where available working space dictates and open cut excavation not feasible. Both methods offer technically effective and offer a cost efficient temporary or permanent means of retaining the sides of bulk excavations even in water bearing strata. When used in permanent works, these walls can be designed to resist vertical loads in addition lateral load from retaining soil. Construction of both methods is the same as for foundation bearing piles. Contiguous walls are constructed with small gaps between adjacent piles. The spacing of the piles can be varied to provide suitable bending stiffness.

Secant piled walls

[edit]

Secant pile walls are constructed such that space is left between alternate 'female' piles for the subsequent construction of 'male' piles.[clarification needed] Construction of 'male' piles involves boring through the concrete in the 'female' piles hole in order to key 'male' piles between. The male pile is the one where steel reinforcement cages are installed, though in some cases the female piles are also reinforced.[citation needed]

Secant piled walls can either be true hard/hard, hard/intermediate (firm), or hard/soft, depending on design requirements. Hard refers to structural concrete and firm or soft is usually a weaker grout mix containing bentonite.[citation needed] All types of wall can be constructed as free standing cantilevers, or may be propped if space and sub-structure design permit. Where party wall agreements allow, ground anchors can be used as tie backs.

Slurry walls

[edit]

A slurry wall is a barrier built under ground using a mix of bentonite and water to prevent the flow of groundwater. A trench that would collapse due to the hydraulic pressure in the surrounding soil does not collapse as the slurry balances the hydraulic pressure.

Deep mixing/mass stabilization techniques

[edit]

These are essentially variations of in situ reinforcements in the form of piles (as mentioned above), blocks or larger volumes.

Cement, lime/quick lime, flyash, sludge and/or other binders (sometimes called stabilizer) are mixed into the soil to increase bearing capacity. The result is not as solid as concrete, but should be seen as an improvement of the bearing capacity of the original soil.

The technique is most often applied on clays or organic soils like peat. The mixing can be carried out by pumping the binder into the soil whilst mixing it with a device normally mounted on an excavator or by excavating the masses, mixing them separately with the binders and refilling them in the desired area. The technique can also be used on lightly contaminated masses as a means of binding contaminants, as opposed to excavating them and transporting to landfill or processing.

Materials

[edit]

Timber

[edit]

As the name implies, timber piles are made of wood.

Historically, timber has been a plentiful, locally available resource in many areas. Today, timber piles are still more affordable than concrete or steel. Compared to other types of piles (steel or concrete), and depending on the source/type of timber, timber piles may not be suitable for heavier loads.

A main consideration regarding timber piles is that they should be protected from rotting above groundwater level. Timber will last for a long time below the groundwater level. For timber to rot, two elements are needed: water and oxygen. Below the groundwater level, dissolved oxygen is lacking even though there is ample water. Hence, timber tends to last for a long time below the groundwater level. An example is Venice, which has had timber pilings since its beginning; even most of the oldest piles are still in use. In 1648, the Royal Palace of Amsterdam was constructed on 13,659 timber piles that still survive today since they were below groundwater level. Timber that is to be used above the water table can be protected from decay and insects by numerous forms of wood preservation using pressure treatment (alkaline copper quaternary (ACQ), chromated copper arsenate (CCA), creosote, etc.).

Splicing timber piles is still quite common and is the easiest of all the piling materials to splice. The normal method for splicing is by driving the leader pile first, driving a steel tube (normally 60–100 cm long, with an internal diameter no smaller than the minimum toe diameter) half its length onto the end of the leader pile. The follower pile is then simply slotted into the other end of the tube and driving continues. The steel tube is simply there to ensure that the two pieces follow each other during driving. If uplift capacity is required, the splice can incorporate bolts, coach screws, spikes or the like to give it the necessary capacity.

Iron

[edit]

Cast iron may be used for piling. These may be ductile.[citation needed]

Steel

[edit]
Cutaway illustration. Deep inclined (battered) pipe piles support a precast segmented skyway where upper soil layers are weak muds.

Pipe piles are a type of steel driven pile foundation and are a good candidate for inclined (battered) piles.

Pipe piles can be driven either open end or closed end. When driven open end, soil is allowed to enter the bottom of the pipe or tube. If an empty pipe is required, a jet of water or an auger can be used to remove the soil inside following driving. Closed end pipe piles are constructed by covering the bottom of the pile with a steel plate or cast steel shoe.

In some cases, pipe piles are filled with concrete to provide additional moment capacity or corrosion resistance. In the United Kingdom, this is generally not done in order to reduce the cost.[citation needed] In these cases corrosion protection is provided by allowing for a sacrificial thickness of steel or by adopting a higher grade of steel. If a concrete filled pipe pile is corroded, most of the load carrying capacity of the pile will remain intact due to the concrete, while it will be lost in an empty pipe pile. The structural capacity of pipe piles is primarily calculated based on steel strength and concrete strength (if filled). An allowance is made for corrosion depending on the site conditions and local building codes. Steel pipe piles can either be new steel manufactured specifically for the piling industry or reclaimed steel tubular casing previously used for other purposes such as oil and gas exploration.

H-Piles are structural beams that are driven in the ground for deep foundation application. They can be easily cut off or joined by welding or mechanical drive-fit splicers. If the pile is driven into a soil with low pH value, then there is a risk of corrosion, coal-tar epoxy or cathodic protection can be applied to slow or eliminate the corrosion process. It is common to allow for an amount of corrosion in design by simply over dimensioning the cross-sectional area of the steel pile. In this way, the corrosion process can be prolonged up to 50 years.[citation needed]

Prestressed concrete piles

[edit]

Concrete piles are typically made with steel reinforcing and prestressing tendons to obtain the tensile strength required, to survive handling and driving, and to provide sufficient bending resistance.

Long piles can be difficult to handle and transport. Pile joints can be used to join two or more short piles to form one long pile. Pile joints can be used with both precast and prestressed concrete piles.

Composite piles

[edit]

A "composite pile" is a pile made of steel and concrete members that are fastened together, end to end, to form a single pile. It is a combination of different materials or different shaped materials such as pipe and H-beams or steel and concrete.

'Pile jackets' encasing old concrete piles in a saltwater environment to prevent corrosion and consequential weakening of the piles when cracks allow saltwater to contact the internal steel reinforcement rods

Construction machinery for driving piles into the ground

[edit]

Construction machinery used to drive piles into the ground:[15]

  • Pile driver is a device for placing piles in their designed position.
  • Diesel pile hammer is a device for hammering piles into the ground.
  • Hydraulic hammer is removable working equipment of hydraulic excavators, hydroficated machines (stationary rock breakers, loaders, manipulators, pile driving hammers) used for processing strong materials (rock, soil, metal) or pile driving elements by impact of falling parts dispersed by high-pressure fluid.
  • Vibratory pile driver is a machine for driving piles into sandy and clay soils.
  • Press-in pile driver is a machine for sinking piles into the ground by means of static force transmission.[16]
  • Universal drilling machine.

Construction machinery for replacement piles

[edit]

Construction machinery used to construct replacement piles:[15]

  • Sectional Flight Auger or Continuous Flight Auger
  • Reverse circulation drilling
  • Ring bit concentric drilling
